DIY Pickup Truck Hoist

$14.95Instant download only

SKU: 3KTLP1010 Category:

Description

DIY PICKUP TRUCK HOIST



DIY Plans to build your own?3000 lb. Electric Pickup Truck Hoist – Pickup Truck Mounted Cranes. Build and use this 3,000 lb electric truck hoist for your 1/2 ton or 3/4 ton pickup truck. This handy unit will lift all of your heavy projects into the back of your pickup truck with ease.
Build Your Own Electric
DIY Pickup Truck Hoist

COMPLETE
Pick Up Truck Mounted Cranes
—-PLANS FOR BUILDING—
3000 lb Electric Truck Mounted Crane

??WHAT ARE IN THE PLANS?

COMPLETE BILL OF MATERIALS SHOW ALL STOCK STEEL PARTS REQUIRED

COMPLETE LIST OF PURCHASED PARTS & SUPPLIERS W/TELEPHONE NUMBERS – WEBSITES

THESE PLANS ARE THE ACTUAL SHOP PRODUCTION PLANS COMPLETE!

SIMPLE DESIGN

Build Your Own Pick up truck crane – Electric Pickup truck hoist
Lift everything anything heavy from heavy duty generators, concrete items such as concrete steps or burial vaults, large propane tanks and more. Save time lifting and hauling with this electric trunk mounted crane. Adjust the side rail height to lift taller items.

SPECIFICATIONS

Lift Up to 3,000 lbs.
Fits 1/2 Ton or 3/4 Ton Pickup Truck
Pendant Control
12 Volt Electric Cable Winch Design
Trolley Travel In – Out
Steel Construction
Easy to use
Easy to build

MONEY BACK NO RISK GUARANTEE
If for some reason you do not like our plans or feel they are incomplete we will refund your money no questions asked. We are very confident that you will find these plans to be VERY thorough!

COMPLETE SUPPLIERS LIST AND MATERIAL LIST
SHOP DRAWINGS
PLUS

Our engineering staff will assist you all the way through construction.
Help is just a phone call or e-mail away!

YOUR COST FOR ENTIRE DOWNLOADABLE SET OF PLANS
ONLY – $14.95!!
Source Steel Locally
Steel can usually be sourced locally, most supply houses will even cut everything to size right according to the shop layout drawings.
Easy To Build
These plans are very basic and any welder could easily build the frame for your truck in one weekend with all supplies on hand. We have all of the supplies sourced out for you!
Save Money & Build Your Own
Pickup Truck Hoist – Pickup Truck Mounted Crane
CLICK ON THE LINK AT THE TOP OF THE PAGE FOR
INSTANT DOWNLOAD
COMPLETE PLANS ONLY $14.95
